Communication:

• Modbus: support for TCP and UDP
• ETHERNET:
  • EtherNet/IP™ adapter (slave)
  • library for e!RUNTIME
  • MQTT protocol

ETHERNET protocols:

• DHCP
• DNS
• NTP
• FTP
• FTPS
• SNMP
• HTTP
• HTTPS
• SSH

Visualization:

• web visualization

Operating system:

• Real-time Linux 3.18 (with RT preemption patch)

CPU:

• Cortex A8; 600 MHz

Programming languages ​​according to IEC 61131-3:

• instruction list (IL)
• ladder diagram (LD)
• Function Plan (FUP)
• signal flow chart (CFC)
• Structured Text (ST)
• Sequential Function Chart (SFC)

programming environment:

• e!COCKPIT (based on CODESYS V3)

Configuration options:

• e!COCKPIT
• WAGO-I/O-CHECK
• web-based management

Transmission rate (communication/fieldbus 1):

• 10/100 Mbit/s

Transfer rate (ETHERNET):

• 10/100 Mbit/s

Transmission medium (communication/fieldbus):

• ETHERNET: Twisted Pair S-UTP; 100 Ω; Cat. 5; 100 m maximum cable length

Memory:

• Main memory (RAM): 256 MB
• Internal memory (Flash): 256 MB
• Remanent memory hardware: 64 kByte
• Program memory: 12 MB (program and data memory, dynamically distributed)
• Data storage: 12 MB (dynamically distributed)
• Remanent memory software: 64 kByte

Memory card type:

• microSD up to 32 GB (All guaranteed properties are only valid in conjunction with the WAGO memory card.)

Memory card slot:

• Push/Push mechanism; cover flap can be sealed

Module capacity:

• Number of modules per node max.: 250
• Number of modules without bus extension max.: 64

Input and output process image:

• Internal: max. 1000 words/1000 words
• Modbus®: CODESYS V3: 32,000 words/32,000 words

Display elements:

• LED (SYS, RUN, I/O, USR) in red/green/orange: status system, program, local bus, user-programmable status (can be used via CODESYS library)
• LED (A, B) in green: Status system supply, field supply

Supply:

• System supply:
  • Voltage: DC 24 V (-25 … +30 %); via wiring level (CAGE CLAMP® connection)
  • Input current typ. at rated load (24 V): 550 mA
  • Total current for system supply: 1,700 mA
• Field supply:
  • Voltage: DC 24 V (-25 … +30 %); via power contacts
  • Current carrying capacity of the power contacts: 10 A
  • Number of power contacts outgoing: 3

Potential separation:

• 500 V between system and field
