Wago 750-530 8-channel digital output DC 24 V 0.5 A Number of digital outputs 8 Total number of channels (module) 8 signal type Digital Signal type Voltage DC 24 V actuator connection 8 x (1 conductor) output characteristic positive switching output current per channel 0.5A output current short-circuit proof switching frequency max. 2 kHz Load type ohmic, inductive, lamp load Absorbable energy max. (single shutdown) 0.9J Data width output data (internal) max. 8 bit Supply voltage system DC 5 V; via data contacts Current consumption system supply (5 V) 25mA Field supply voltage DC 24 V (-25 … +30 %); via power contacts (supply via blade contact; forwarding (only field side supply voltage) via spring contact) Current consumption field supply (module without external load) 15mA Potential separation 500 V system/field Display elements LED (AH) green: Status DO 1 … DO 8 Number of incoming power contacts 2 Number of power contacts outgoing 2 current carrying capacity of the power contacts 10A
