Wago 750-519 4-channel digital output DC 5V 20mA Number of digital outputs 4 Total number of channels (module) 4 signal type Digital Signal type Voltage DC 5 V Actuator connection 2 x (2 conductors); to connect additional actuators, a suitable potential multiplication module (e.g. 750-614) must also be used. output characteristic positive switching output current per channel 0.02A output current short-circuit proof switching frequency max. 5 kHz Load type ohmic, inductive, lamp load Data width output data (internal) max. 4 bit Supply voltage system DC 5 V; via data contacts Current consumption system supply (5 V) 10mA Supply voltage field DC 5 V; via power contacts (supply via blade contact; forwarding (only supply voltage field side) via spring contact) Current consumption field supply (module without external load) 14mA Potential separation 500 V system/field Display elements LED (AD) green: Status DO 1 … DO 4 Number of incoming power contacts 2 Number of power contacts outgoing 2 current carrying capacity of the power contacts 10A
