Wago 750-467 2-channel analog input DC 0 … 10 V single-ended
Wago 750-467 2-channel analog input DC 0 … 10 V single-ended
Regular price
€164,89 EUR
Regular price
Sale price
€164,89 EUR
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Wago 750-467 2-channel analog input DC 0 … 10 V single-ended
- number of analog inputs 2
- Total number of channels (module) 2
- signal type Tension
- signal type voltage DC 0 … 10 V
- sensor connection 2 x (2 conductors)
- input voltage max. 35 V
- signal characteristics single-ended
- resolution [bit] 12-bit
- data width 2 x 16 bit data; 2 x 8 bit control/status (optional)
- internal resistance 130kΩ
- Conversion time typ. 2ms
- measurement error, reference temperature 25°C
- Measurement error, maximum deviation from the measuring range end value 0.2%
- Temperature error max. from the measuring range end value 0.01%/K
- supply voltage system DC 5 V; via data contacts
- current consumption system supply (5 V) 60mA
- potential separation 500 V system/field
- display elements LED (A, C) green: Function AI 1, AI 2
Share
1 in stock
