Wago 750-414 4-channel digital input, DC 5V, 0.2ms Number of digital inputs 4 Total number of channels (module) 4 signal type Digital Signal type Voltage DC 5 V sensor supply DC 5 V Sensor connection 2 x (2 conductors, 3 conductors); to connect additional sensors, a suitable potential multiplication module (e.g. 750-614) must also be used. input characteristic positive switching input filter (digital) 0.2ms Input current per channel for signal (1) typ. 0.05mA Voltage range for signal (0) DC 0 … 0.8 V Voltage range for signal (1) DC 2.4 … 5 V Data width input data (internal) max. 4 bit Supply voltage system DC 5 V; via data contacts Current consumption system supply (5 V) 5mA Supply voltage field DC 5 V; via power contacts (supply via blade contact; forwarding (only supply voltage field side) via spring contact) Potential separation 500 V system/field Display elements LED (AD) green: Status DI 1 … DI 4 Number of incoming power contacts 2 Number of power contacts outgoing 2 current carrying capacity of the power contacts 10A
