General technical data

• Type : Digital Edition
• Equipment : 16 outputs (relays)
• Potential separation : Yes
• Operating voltage : AC 5 V to AC 230 V
• Output current per channel : Max. 5 A

Electrical Specifications

• Switching voltage : AC 5–230 V
• Switching current :
  • Maximum per output : 5 A
  • Total switching current (all outputs) : Limited depending on power supply
• Contact type : Relay output (potential-free)
• Switching frequency :
  • Mechanical : Max. 20 Hz
  • Electrical : Max. 0.5 Hz (depending on load and voltage)
• Switch-on delay : Typically 8–10 ms
• Switch-off delay : Typically 3–5 ms

Mechanical data

• Dimensions (WxHxD) : 40 mm x 290 mm x 210 mm (depending on model variant)
• Weight : Approx. 500–600 g
• Connection type : spring terminals or screw terminals (depending on the variant)
• Mounting : Suitable for 19-inch racks or DIN rails

environmental conditions

• Operating temperature : 0 °C to +60 °C
• Storage temperature : -40 °C to +70 °C
• Protection class : IP20
• Relative humidity : 5–95% (without condensation)
