Technical data:

• Type: AC/DC interface converter
• Operating voltage: 24 V AC/DC
• 2-way separation: Electrical separation between input and output for increased safety and prevention of interference

Entrance:

• Voltage input: 0-10 V
• Power input: 0-20 mA or 4-20 mA

Exit:

• Voltage output: 0-10 V
• current output: 0-20 mA or 4-20 mA

Connection:

• screw connection: For safe and stable electrical connections

Special features:

• 2-way separation: Prevents feedback from the output to the input and protects the electronics.
• Wide-area coverage: Can be operated with both 24 V AC and DC.
