Sick 6044692 COMPACT LIGHT SENSORS WTB250-2P2451

functional principle

• Functional principle: reflection light sensor with background suppression

dimensions and housing

• Dimensions (WxHxD): 20 mm x 65 mm x 43.9 mm
• Housing shape (light emission): cuboid-shaped

switching distance and focus

• Maximum switching distance: 200 mm ... 1,000 mm
• Switching distance: 200 mm ... 1,000 mm
• Focus: Approx. 3° beam angle

light source and light parameters

• Light type: Visible red light
• light source: LED
• Light spot size at 1,000 mm: Ø 35 mm
• Beam angle: Approx. 3°

setting options

• Setting method: potentiometer, 2 turns

order information

• Type: WTB250-2P2451
• Article number: 6044692
• Scope of delivery: BEF-W250 (1)
