Technical data:

Inputs:

• Supports 1-channel and 2-channel circuit .
• With or without cross-circuit detection (Detection of line faults such as short circuits between the signal lines).

Outputs:

• 3 safety relay contacts (S): For the shutdown of dangerous situations.
• 1 feedback output (Ö): Monitors the status of the safety function.
• 1 auxiliary contact (HL): For diagnostic or signaling functions.

Startup options:

• Automatic start: Starts automatically after an error condition is eliminated.
• Monitored start: Requires manual acknowledgement to restart.

Electrical characteristics:

• Supply voltage (UB): 24 V AC/DC, suitable for industrial power supplies.

Mechanical properties:

• Width: 45 mm, compact design for space-saving control cabinet installation.
• Connection: Integrated screw terminals, easy to wire.

Monitoring functions:

• Emergency stop: Monitoring and safe shutdown in case of emergency.
• Safety doors: Prevents the machine from operating when the safety doors are open
