Technical data:

• Supply voltage: 24 V DC
• Inputs:
  • 8 digital inputs
  • Of these, 2 inputs (I7 and I8) can be used as analog inputs (0–10 V)
• Outputs:
  • 4 relay outputs
  • Maximum switching current per output: 8 A
• Integrated functions:
  • real-time clock with calendar function
  • time relay and counter functions
  • timer function
• Programmable functions:
  • logic functions (AND, OR, etc.)
  • time and counting functions
  • text ads
• programming interface:
  • Direct programming via the integrated display and keypad
  • Optional: Programming via PC with the EASY-SOFT software
• Advertisement:
  • LCD display with 4 lines of 12 characters each
• Dimensions:
  • Width: 71.5 mm
  • Height: 90 mm
  • Depth: 58 mm
• Assembly:
  • top hat rail mounting (DIN rail)
• Operating temperature range:
  • -25 °C to +55 °C
