main features

1. Freely programmable with Niagara NX:

   • Supports Niagara 4 for unified engineering across the entire building management system.
   • Enables offline engineering (back office preparation) and live engineering (real-time programming).

2. Multifunctional integration:

   • Control of HVAC, lights and blinds.
   • Integration of various devices via:
     • BACnet MS/TP : Communication via RS485.
     • Modbus RTU : For wall modules, I/O modules, sensors and VAV dampers.
     • SYLK bus : For Honeywell room control units such as CLCMTR40x/-TR42x.
     • RJ45 : Connector for Honeywell BACnet WiFi Adapter (BACA-A).

3. Energy efficiency and comfort:

   • High energy savings through demand-based control.
   • Increases the comfort and well-being of users.

4. Optimized installation and commissioning:

   • Cost-efficient mounting on DIN rails, in control cabinets or on the wall.
   • Protection class: IP20 (optionally extendable to IP30 with terminal cover).

Technical specifications

• communication interfaces:

  • RS485 : For BACnet MS/TP.
  • Modbus RTU : For the integration of external devices.
  • SYLK bus : Internal bus for Honeywell accessories.
  • RJ45 : For BACnet WiFi adapter.

• Mounting types:

  • DIN rail.
  • In control cabinets or fuse boxes.
  • Direct wall mounting.

• Protection class:

  • IP20 (optionally IP30).

• Software:

  • Freely programmable with Niagara 4.
  • Adaptation to specific requirements in building management.

possible uses

• Ideal for complex building management systems that integrate multiple trades.
• Perfect for office buildings, hotels, schools and other facilities where HVAC, lights and blinds need to be individually controlled.
