Festo 175252 pressure switch PEV-1/4-A-SW27-B-OD series R3

• Symbol number : 00991472
• CE mark : Conformity with EU Low Voltage Directive (see declaration of conformity)
• UKCA mark : Conformity to UK regulations for electrical equipment (see declaration of conformity)
• Measured quantity : relative pressure
• Measuring method : Pneumatic-electrical pressure transducer
• Operating pressure : 1 bar ... 10 bar
• Operating medium : compressed air according to ISO 8573-1:2010 [7:-:-]
• Medium temperature : -20 °C ... 80 °C
• Ambient temperature : -30 °C ... 100 °C
• Switching element function : changeover contact
• Max. switching frequency : 3 Hz
• Max. switching output voltage (AC) : 250 V
• Max. switching output voltage (DC) : 250 V
• Max. output current : 4000 mA
• Electrical connection : 4-pin
• Connector : Integrated
• Mounting type : Screw-in
• Installation position : Any
• Pneumatic connection : G1/4
• Product weight : 900 g
• Housing material : PA66-GF30, galvanized steel
• Membrane material : NBR
• Setting range threshold values : 1 bar ... 10 bar
• Protection class : IP65
• LABS conformity : VDMA24364-B1/B2-L
