Beckhoff KL9020 internal bus extension end terminal

Beckhoff KL9020 internal bus extension end terminal

€123,49 EUR
€123,49 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.

Beckhoff KL9020 internal bus extension end terminal

  • number of coupler terminals up to 31 KL9050
  • current load –
  • power LED –
  • defective LED –
  • type/number of peripheral signals bus coupler dependent
  • Max. number of bytes fieldbus bus coupler dependent
  • length between stations max. 5 m between KL9020 and KL9050
  • bus interface 1 x RJ45 socket
  • inrush current –
  • current consumption K-Bus 70 mA typ.
  • K-Bus power supply –
  • power contacts max. 24 V DC/max. 10 A
  • nominal voltage –
  • potential separation 500 V (power contact/supply voltage/K-bus)
  • configuration option none, automatic
  • PE contact –
  • shield connection –
  • Electrical connection to the DIN rail –
  • Special features end terminal for K-Bus extension
  • Weight approx. 45 g
  • operating/storage temperature 0…+55 °C/-25…+85 °C
  • Relative humidity 95% without condensation
  • vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27
  • EMC immunity/emission according to EN 61000-6-2/EN 61000-6-4
  • protection class/installation position IP20/any
  • approvals/markings CE, UL, ATEX, IECEx, DNV GL
  • Ex marking ATEX:
  • II 3 G Ex nA IIC T4 Gc
  • IECEx:
  • Ex ec IIC T4 Gc

2 in stock

View full details
