Wago 750-314, MODBUS fieldbus coupler, RS-232, 19.2 kBd

Wago 750-314, MODBUS fieldbus coupler, RS-232, 19.2 kBd

€379,99 EUR
€379,99 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.
Wago 750-314, MODBUS fieldbus coupler, RS-232, 19.2 kBd
  • communication Modbus RTU
  • Number of fieldbus nodes on the master max. 99
  • number of I/O points 6,000
  • transfer rate 150 volumes … 19.2 kB
  • Bus segment length max. 1200 m
  • transmission medium shielded copper cable 2 (4) x 0.25 mm²
  • Number of modules per node max. 64
  • Input and output process image (fieldbus) max. 512 bytes/512 bytes
  • supply voltage system DC 24 V (-25 … +30 %); via wiring level (CAGE CLAMP® connection)
  • current consumption system supply (5 V) 350mA
  • total current for system supply 1,650mA
  • supply voltage field DC 24 V (-25 … +30 %); via power contacts
  • Input current typ. 500mA
  • Power supply efficiency typ. at rated load (24 V) 87%
  • potential separation 500 V system / supply
  • Number of power contacts outgoing 3
  • current carrying capacity of the power contacts 10A

1 in stock
